Description
Designed and handcrafted using carefully selected combinations of 5N OCC solid silver conductors and Duelund tinned copper conductors, the Ultimate Silver Series is meticulously fine-tuned to achieve exceptional sound quality, musicality, and tonal balance.
Audiolund XLR to RCA/RCA to XLR Interconnect Cable ~ Ultimate Silver Series
- Upgraded Version: The XLR/RCA cable construction has been further refined to enhance overall sound quality.
1. Standard XLR to RCA format
- Constructed according to the standard XLR-to-RCA configuration, with Pin 1 and Pin 3 connected to ground, suitable for transformer-coupled outputs.
- Uses 9 solid-core 5N OCC silver conductors in multiple gauges: 15AWG + 18AWG + 24AWG + 26AWG + 28AWG + 29AWG + 29AWG + 32AWG + 32AWG, applied to both positive and negative signal paths.
- Each positive and negative signal path also incorporates 1 × 16AWG Duelund tinned copper conductor, blended with the 5N OCC silver conductors.
- For a 1.0-meter pair, the total conductor usage is approximately:
- 4m × 9 solid-core 5N OCC silver conductors, ranging from 15AWG to 32AWG
- 4m × 16AWG Duelund tinned copper conductor
- 2m silver-plated copper conductor for grounding
2. XLR to RCA with Pin-3 Open
- Constructed according to the Pin 3 open configuration used by MERGING+NADAC, Benchmark, Weiss, and other designs.
- The positive signal path incorporates 1 × 16AWG Duelund tinned copper conductor together with 5N OCC silver conductors.
- Uses 9 solid-core 5N OCC silver conductors in multiple gauges: 15AWG + 18AWG + 24AWG + 26AWG + 28AWG + 29AWG + 29AWG + 32AWG + 32AWG in the positive signal path.
- For a 1.0-meter pair, the total conductor usage is approximately:
- 2m × 9 solid-core 5N OCC silver conductors, ranging from 15AWG to 32AWG
- 2m × 16AWG Duelund tinned copper conductor
- Tinned copper shielding for grounding
3. XLR to RCA with Pin-3 Open added 10K Ohm resistor to ground
- Multiple types and layers of shielding materials are used to help minimize noise and RFI/EMI interference.
- A dedicated damping design incorporates various anti-vibration and isolation materials to help suppress mechanical vibration.
- Standard length: 1.0m, with other lengths available.
Sound Characteristics
The Ultimate Silver Series combines key sonic characteristics of the Xtreme Series and True Silver Series.
It delivers the natural, smooth, full-bodied, and musical presentation associated with the Xtreme Series and its Western Electric-inspired character, together with a quiet background. At the same time, the 5N OCC silver conductors contribute the sweetness, delicacy, speed, power, detail, and dynamic response associated with high-purity silver.
The combination creates a highly refined and comprehensive presentation that balances musical warmth and naturalness with modern silver clarity, speed, and resolution.
Using a combination of XLR and RCA connectors, this cable functions as an unbalanced XLR/RCA interconnect.
Conductor Cross-Sectional Area
For the Ultimate Silver Series RCA/XLR Interconnect, the estimated conductor cross-sectional area per meter, per +/- channel, is:
- 5N OCC Silver: 3.13 mm²
- Duelund Tinned Copper: 1.31 mm²
Choosing Between Audiolund’s Top Five Series
As a simple guide, each series is designed around a different sonic character:
- If you prefer the classic vintage Duelund/Western Electric sound, consider the Xtreme Series.
- If you prefer a modern 5N pure silver presentation, consider the True Silver Series.
- If you prefer the Duelund/Western Electric character with added pure silver characteristics, consider the Xtreme Silver Series.
- If you prefer the 5N pure silver character with added vintage Duelund/Western Electric qualities, consider the Ultimate Silver Series.
- If you value the Duelund/Western Electric and modern pure silver characteristics equally, consider the Flagship Series.
Recommendation
If you enjoy both the Western Electric-style character and pure silver sound, the Xtreme Silver Series and Ultimate Silver Series are both excellent choices.
The Ultimate Silver Series places greater emphasis on the modern high-purity silver presentation. By incorporating Duelund tinned copper conductors, it adds greater musicality, body, smoothness, and a slightly softer tonal character.
Highly recommended for listeners seeking the resolution and speed of OCC silver without sacrificing naturalness and musicality.
1) Default: Gold Foil + Black Stripe on Black Background
- Provides better wear resistance for the red copper and plastic decorative strips.
2) Silver Foil + Transparent Strip on Black Background
- The silver foil has lower wear resistance and should therefore be handled with greater care.
Cable Run-In
Most Audiolund cables use multi-core designs incorporating multiple conductor types and gauges. As a result, sufficient run-in time is recommended before making a final assessment of their sound.
The relatively thick solid-core OCC silver conductors may require a longer run-in period than Duelund tinned copper conductors, which use multiple parallel thin strands.
As a general guideline:
- Most Audiolund cables: approximately 100–200 hours
- Ultimate Silver Series: approximately 200–400 hours
The Ultimate Silver Series uses a particularly complex combination of multiple solid-core OCC silver conductors and Duelund tinned copper conductors and may therefore require additional run-in time before reaching a stable sonic presentation.
